SQL vs NoSQL vs NewSQL: The Full Comparison

Navdeep Singh Gill | 11 October 2024

SQL vs NoSQL vs NewSQL: The Full Comparison
13:54
XenonStack Feature Image

Overview of SQL vs. NoSQL vs. NewSQL

These are the types of databases, and in the upcoming paragraph, you will understand each of them. SQL Databases can also be termed Relational Database management Systems, also known as RDBMS, a classical approach to storing and operating historical data. In such a system, the information follows a structured approach utilizing tables or relations.



With the advent of Big Data, the structured approach fails miserably to cater to the needs of the humongous information processing that tends to be unstructured in nature. Over time SQL has undergone many iterations to support the vast quantity of data processing and pipelines. However, it is still inefficient to answer Big Data systems expecting a quick response and supreme scalability.


NewSQL is a term that’s used to describe product offerings that support the relational data model while delivering the same scalable performance of NoSQL database systems. Source: A NewSQL Database For Enterprises

A new approach known as NoSQL was introduced was devised to work around the limitations imposed by the former. Its system was designed to provide fast scalability when dealing with unstructured data platforms or handling Big Data applications. Its databases use a key-value pair, Documents, graph databases, or wide–column stores without a typical schema. It is also horizontally scalable as opposed to only vertical scaling in RDBMS. It showed great promise to be an ideal database system for Big Data applications, but like anything else, it fell short due to some major drawbacks discussed below. This is where NewSQL came alive. NewSQL is the latest development in the world of database systems. NewSQL is a relational database with the scalable properties of it.


What is SQL Relational Database?

 The term SQL is both a language and a type of database. It stood for structured query language and was the pioneer of database design philosophy. Since the mid-’80s, it has been a standard for managing and querying relational datasets; however, the early beginnings of the relational model can be dated back to the ’60s and ’70s when the urgent need to distinguish between the application data and application code emerged, allowing the developers to focus on other aspects of the program development such as access to and manipulation of data at hand. IBM’s IMS was the first fully functional relational database, albeit designed for a different purpose, to organize data for the Apollo space exploration program. The relational database is a collection of time-varying, normalized relations of assorted degrees. The following intuitive correspondence can be made.
  • A relation is a file

  • Each file contains only one record type

  • The records have no particular order

  • Every field has a single-value

  • The records have a unique identifying field, or composite field called the primary key field

What are the Concepts of SQL Relational Databases?

The concepts of SQL Relational Databases are below:

ACID

Atomicity, Consistency, Isolation, and Durability to maintain the reliability of transactions.
  1. Atomicity – completion of the transaction as a whole or none at all
  2. Consistency – assures the stable state of the database with or without changes
  3. Isolation – multiple transactions do not interfere with each other
  4. Durability – permanent effect on the database by the changes

Normalization

A process of designing efficient databases
  • 1NF – Split the table by separating repeating and nonrepeating attributes. All domains are simple, and all elements are atomic

  • 2NF – Remove partial dependency between attributes. No attribute should be functionally dependent on one part of an aggregated primary key.

  • 3NF – Remove transitive dependency between table attributes. No prime attribute is functionally dependent on the non-prime attribute.

Scalability

The capability of the database to handle growing amounts of data. Vertical scaling helps to enhance the existing capacity of the database server. Most SQL databases support vertical scaling. They can, however, scale up, not scale out.

Domains

A domain is a named set of scalar values, all of the same type. They help to impose semantic constraints. Rely on traditional features and utilize a defined data schema. Support JOIN functionality, engineered for data integrity


Not-only-SQL are the databases that let the developers store/manage unstructured data and perform complex analytical operations on it. Source: Overview of NoSQL Databases

What are the Drawbacks?

Although RDBMS provides exclusive features, they suffer greatly from some major drawbacks

The Rigidity of Data Modeling

One of the relational database's biggest limitations is the rigidity of organizing the data into a particular structure in tables and relations. Since all the data cannot be conveniently fitted into tables, this approach can’t be applied to all-natural data and stored as trees and graphs. However, RDBMS works around this limitation by modeling this data in a normalized manner with parent-child relations, which is still not enough.

Diversity

The complexity of the data also creates a limitation in the relational database. These databases are made to organize the data by common characteristics. Complex numbers, images, and multimedia data are hard to store, access, and process.

Inefficient Usage of Space

When we define the schema of the relation, we define the size of all the attributes. Not all the records have data that use the full space. Some have a short length. Every record needn’t necessarily fit into the given data type again, resulting in space wastage.

Heavy Weight Changes

Any changes required for one record must be applied to all of the records, resulting in a heavyweight change. Depending on the size and number of records present, the changes can be expensive and infeasible. Thus, it was challenging to change the schema of an existing database.

Inefficient for Big Data

SQL is not suitable for volume, velocity, and variety of data, rendering it highly inefficient for a cloud-based application

What is NoSQL?

These problems became the impetus for the NoSQL movement in the mid-to-late 2000s. The key working strategy is to forgo strong transactional guarantees and relational models of DBMS in favor of eventual consistency and alternative data models like key-value pairs and graphs.



This was done following the belief that these aspects of existing DBMS inhibit their ability to scale out and achieve the high availability needed to support web apps on the go. The two most well-known systems that followed the creed were Google’s BigTable and Amazon’s Dynamo, which were restricted to use inside their own organizations only, leading to organizations creating their own open-source clones like Facebook’s Cassandra and Powerset’s HBase. By the end of the 2000s, there was a diverse set of scalable and affordable DBMS.

What are the Concepts of NoSQL?

The concepts are listed below:

Lack of schema

Support for structured, semi-structured, and unstructured data. No specific schema is required to be defined before entering data into its databases. New fields can be added, and it also supports nested data implementation and retrieval. Developers can use data type and query options requisite for the specific application, resulting in faster development. Faster Development time is considerably reduced due to no complex SQL queries or join statements.

Auto Balancing

Division of data among multiple servers automatically, with no assistance required from applications.

Integrated Caching

Its database caches data in system memory to increase data throughput and performance in advance. With a simple data model and query language, it offers high scalability and reliability.

The BASE Principle For Transaction

The base is to NoSql as what ACID is to SQL. It ensures that NoSQL databases ensure their reliability despite the loss of consistency. The base stands for Basically Available Soft-state, Eventually consistent. Eventually consistent – The system can become eventually consistent, and information is updated wherever necessary.
Big Data Architecture helps design the Data Pipeline with the various requirements of the Batch and Stream Processing System. Source: Big Data Architecture

What are the drawbacks?

The drawbacks of NoSQL are listed below:

Lack of Consistency

Since these systems prefer availability over consistency, they fail miserably when consistency is the most important thing in financial transactions. The non-synchronization of data nodes risks system failure.

Lack of Analytics

For analytics, you require a relational model to process the data, as a result of which the whole database needs to be converted using some relational model. This leads to increased cost overhead.

Lack of Standardization

No specific language

Security

Doesn’t provide security at the elemental level of data.

Transactional Nature

It is important to facilitate fraud detection before completing the transaction and check for balance while on a call. NoSQL fails when the database needs to compete against high-volume transactions per day, as these require a highly scalable, consistent database.

What is NewSQL?

The early counter-measures to the above approaches were a powerful single node machine that can handle all the transactions, a custom-built middleware system to distribute queries over traditional DBMS nodes. But both of them are prohibitively expensive to carry out. As a result, there was a need for an intermediate database system that combines NoSQL systems' distributed architectures with multiple node concurrency and a whole new storage mechanism. Thus Newsql can be defined as a class of modern relational DBMSs that seek to provide the same scalable performance of NoSQL for OLTP workloads and simultaneously guarantee ACID compliance for transactions as in RDBMS. In other words, these systems want to achieve the scalability of NoSQL without having to discard the relational model with SQL and transaction support of the legacy DBMS.

Concepts of NewSQL

  • Main Memory storage of OLTP databases enables in-memory computations of databases.
  • Scaling out by splitting a database into disjoint subsets called either partitions or shards leads to the execution of a query into multiple partitions and then combining them into a single result.
  • Its systems preserve the ACID properties of databases.
  • Enhanced concurrency control system benefits traditional ones.
  • The presence of a secondary index allows it to support faster query processing times.
  • High availability and Strong data durability are only possible with the use of replication mechanisms.
  • Configure its systems to provide synchronous updates of data over the WAN.
  • Minimizes Downtime and provides fault tolerance with its crash recovery mechanism.

What is the difference Between SQL, NoSQL, and NewSQL?

Feature SQL NoSQL NewSQL
Relational Property Yes, it follows relational modeling to a large extent. No, it doesn't follow a relational model. It was designed to be entirely different from that. Yes, since the relational model is equally essential for real-time analytics.
ACID Yes, ACID properties are fundamental to their application No, rather provides for CAP support Yes, Acid properties are taken care of.
SQL Support for SQL No support for old SQL Yes, proper support and even enhanced functionalities for Old SQL
OLTP Inefficient for OLTP databases. It supports such databases, but it is not the best suited. Fully functionally supports OLTP databases and is highly efficient
Scaling Vertical scaling Only Vertical scaling Vertical + Horizontal scaling
Query Handling Can handle simple queries with ease and fails when they get complex in nature Better than SQL for processing complex queries Highly efficient in processing complex queries and smaller queries.
Distributed Databases No Yes Yes


SQL, NoSQL, or NewSQL – Which is the Best Solution to Big Data?

SQL complies with ACID properties and does well with vertical scalability, while NoSQL offers its own horizontal scaling and provides for BASE properties. However, NoSQL does not play by the ACID rules necessary to maintain a reliable and consistent database. Fast-paced enterprises and organizations generate terabytes of transactional data daily while working in an OLTP system. NewSQL is the ideal choice.



NewSQL improves upon SQL by providing horizontal scalability while maintaining ACID properties. This facilitates working with Big Data by implementing concurrency. It also does well with ACID compliance. Thus, NewSQL seems to have found the sweet spot between speed, scalability, consistency, and availability. Even though it is still in its nascent stage, NewSQL ticks all the right boxes to be an ideal database for Big Data and OLTP applications. You can also explore the difference between Virlet and Kubevirt in this blog.
